The EVS003 – 400S is a remarkable 4 – axis robot. With a maximum reach of 400mm, it offers flexible operation. Its payload capacity includes a rated load of 1kg and a maximum load of 3KG, suitable for various tasks. In terms of inertia, the rated torque is 0.005kg.m² and the maximum torque is 0.05kg.m², ensuring stable running.
| Model | EVS003-400S | |||
| Axis | 4 | |||
| Maximum reach | 400mm | |||
| Payload | Rated Load | 1kg | ||
| Maximum Load | 3KG | |||
| Permissible Inertial | Rated Torque | 0.005kg.m² | ||
| Maximum Torque | 0.05kg.m² | |||
| Position Repeat Accuracy | 1st Axis+2nd Axis | ±0.01mm | ||
| Elevating Axis | ±0.01mm | |||
| Rotation Axis | ±0.01° | |||
| Max Speed | lst Axis | 720 °/sec | ||
| 2nd Axis | 720 °/sec | |||
| Elevating Axis | 1000mm/sec | |||
| Rotation Axis | 2500 °/sec | |||
| Max Operating Area | 1st Axis | ±132 ° | ||
| 2nd Axis | ±141 ° | |||
| Elevating Axis | 170mm | |||
| Rotation Axis | ±360 ° | |||
| Installation Parameters | Floor | |||
| Robot Weight | 13Kg | |||
| Power Consumption | 0.7kw | |||
| Installation Environment |
Temperature | 0~+45℃ | ||
| Humidity | 20~80%RH(No Condensation) | |||
| Vibration | 4.9M/S² or less | |||
